CONSTRUCTION DOCUMENTATION & ENGINEERING
Architectural and engineering for an Accessory Dwelling Unit (ADU) involves all the professional trades to ensure the integrity of the ADU. Below is an example of the key elements involved in ADU architecture and engineering:
Site Civil Drawings
- Foundation Design
- Retaining Walls (if applicable)
- Utility Connections
- Flood and Erosion Control Measures: Grading and Drainage Design
- Septic (if required)
Structural Drawings
- Structure Design/Drawings
- Seismic Design
- Wind Load Analysis
Architectural Drawings
- Accessibility Considerations
- Spatial Organization
- Energy Calculations
Energy Use Modeling Software
- Local Climate Considerations
- Determine Building Envelope Efficiency
- Insulation and Air Sealing
- Interior Finishes
- Exterior Finishes
MEP, Mechanical Electrical Plumbing Drawings
- HVAC System Efficiency
- Lighting Efficiency
- Appliance Energy Use
- Renewable Energy Sources
- Compliance with Energy Codes
- Monitoring and Adjustments
Permits and Approvals
Prepare and submit drawings for necessary building permits. The process of obtaining a building permit for an Accessory Dwelling Unit (ADU) can vary depending on the local jurisdiction. However, here's a general example of the steps you might encounter in the ADU building permit process:
- Engage with Local Authorities
- Submit Permit Application
- Application Review
- Public Notification (if required)
- Permit Approval
